Yokogawa Test & Measurement Releases DLM5000HD Series High Definition Oscilloscopes

Yokogawa Test & Measurement Corporation announces the release of the DLM5000HD series high definition oscilloscopes. Positioned as a high-performance version of the DLM5000 series, the DLM5000HD series expands Yokogawa’s oscilloscope lineup with 500 MHz and 350 MHz frequency bandwidth models that deliver higher resolution for more accurate waveform analysis, and come with features that improve usability and enable easier setup.

The DLM5000HD series consists of two 8-channel models (500 MHz DLM5058HD and 350 MHz DLM5038HD) and two 4-channel models (500 MHz DLM5054HD and 350 MHz DLM5034HD).

The DLM5000HD series offers 12 bit vertical resolution that is 16 times higher than that of the existing DLM5000 series, for greater accuracy in waveform observation. This is particularly beneficial for developers of next-generation inverters, enabling the accurate observation of minute changes in high-speed signals. This allows the detection of phenomena that can cause unexpected anomolies. Another useful feature of the DLM5000HD series is that the time-saving serial bus analysis auto-setup function, which automatically sets the optimal bit rate and threshold level, can now also be used with previously captured waveforms. This means that auto-setup can even be used for low-frequency signals, improving the efficiency of in-vehicle bus development and evaluation work (more info).
