Power Integrations Expands InnoSwitch4-CZ Integrated Switcher Family to 220 W

Power Integrations announced an expanded offering of the InnoSwitch™4-CZ family of high-frequency, zero-voltage switching (ZVS) flyback controller ICs. When paired with Power Integrations' ClampZero™ active-clamp IC and, optionally, the recently announced HiperPFS™-5 GaN-based power-factor corrector, the new ICs easily address the latest USB PD 3.1 specification for adapters and chargers up to 220 W.

Road warriors demand light, compact, powerful adapters capable of rapidly charging all their mission-critical devices. The expanded power range of the new InnoSwitch4-CZ and ClampZero ICs allows charger/adapter designers to easily exceed 23 W per cubic inch for single- and multiple-output USB PD 3.1 certified designs. Even at 220 W of output power, the family’s high efficiency minimizes waste heat; bulky heatsinks are not required on any of the active devices. The maximum switching frequency of up to 140 kHz minimizes transformer size, and the high level of integration approximately halves the number of passive components, MOSFETs and diodes that make safety-compliant PCB layout a challenge.

InnoSwitch4-CZ ICs include a robust 750 V PowiGaN™ primary switch, active clamp drive and synchronous rectification in a compact InSOP™-24D package. Secondary-side sensing – achieved using Power Integrations’ FluxLink™ high-speed communications technology – provides exceptional CV/CC accuracy (more info, graphic: Business Wire).
