Small Footprint 32V Buck Converters from Diodes Support High-Efficiency Automotive PoL Applications

Diodes Incorporated has launched a series of automotive-compliant synchronous buck converters. With 2A and 3A current ratings respectively, the AP6320xQ and AP6330xQ devices support a wide input voltage range, going from 3.8V to 32V. They are suited for automotive point-of-load (PoL) applications, including powertrains, instrumentation clusters, telematics, and infotainment systems. They can also benefit the performance of automotive body electronics and lighting, plus advanced driver assistance system (ADAS) implementations.

The AP6320xQ devices integrate 125/68mΩ high/low-side power MOSFETs and the AP6330xQ devices integrate 70/40mΩ high/low-side power MOSFETs, enabling both to deliver high-efficiency step-down DC-DC conversion, while keeping the external component count to a minimum. Adoption of peak current mode control and use of integrated loop compensation networks help streamline deployment.

The proprietary gate driver arrangement in these buck converters mitigates switching node ringing effects, without lengthening MOSFET turn-on and turn-off times. This considerably reduces the high frequency radiated electromagnetic interference (EMI) noise normally associated with MOSFET switching (more info).
