Rohde & Schwarz presents new software for three-phase power analysis on MXO series oscilloscopes

With the new R&S MXO-K333 3-phase power analysis software option, Rohde & Schwarz brings power analyzer-style insights directly to its MXO series oscilloscopes. Designed for engineers developing and debugging three-phase AC systems, the option delivers more than numerical results alone. It combines key power measurements with full waveform visibility, enabling users to quickly correlate power behavior with real signal events and troubleshoot issues faster.

Rohde & Schwarz has introduced the new R&S MXO-K333 software option for three-phase power analysis on its MXO series oscilloscopes. The software adds in-depth measurement and analysis functions for testing and debugging three phase power systems, drives and inverters.

Available for all four and eight channel models of the MXO 3, MXO 4, MXO 5 and MXO 5C oscilloscopes, it supports the analysis of voltage and current signals in three-phase AC systems. This innovative test solution keeps the captured waveforms visible during measurement, allowing engineers to review power values and check transient behavior in the same instrument. Other oscilloscope functions such as math, spectrum analysis, measurement tracking and zone trigger remain available for further analysis (more info).
